Nomad® 40-12681 1 1/2" Flanged PWR-FLO™ AODD Pump, Polypropylene w/ Viton/FKM Diaphragm; Model Code NPF40/PPPP/VT/VT/PTV/FL/B

Part Number: 40-12681
The actual product may vary from images shown
$3,440.65
QTY:


40-12681 DETAILS

Nomad® 40-12681 1 1/2" Flanged PWR-FLO™ AODD Pump, Polypropylene w/ Viton/FKM Diaphragm

The PWR-FLO asymmetrical spool design (ASD) features the most efficient air system available. The anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applications. The air valve and center section is made of chemically resistant polypropylene. Similar and Comparable to Wilden® Standard P Series "Pro-Flo® Valve Design". Model: NPF40/PPPP/VT/VT/PTV/FL/B Porting Position: Side Port Flanged

  • Wetted Material: Polypropylene
  • Center Block: Polypropylene
  • Air Chamber: Polypropylene
  • Air Valve: Polypropylene
  • Diaphragm: Viton/FKM
  • Ball: Viton/FKM
  • Connection Type: Flanged
  • Bolted

Model Code NPF40/PPPP/VT/VT/PTV/FL/B

40-12681 FEATURES
  • Drop in replacement for Wilden® AODD pumps of equivalent make and size
  • Air driven double diaphragm pumps handle large solids and slurries
  • PWR-FLO™ asymmetrical spool design (ASD) features an efficient air system
  • The anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applications
  • The air valve and center section is made of chemically resistant polypropylene.

40-12681 SPECS

  • Pump Type: PWR-FLO NPF40
  • Brand: NOMAD®
  • Wetted Parts: Polypropylene
  • Non-Wetted Material:
  • Air Inlet Size: 0.5
  • Air Consumption:
  • Air Valve Material: Polypropylene
  • Max Air Inlet Pressure: 125 PSIG
  • Ball Material: Viton/FKM
  • Air Inlet Connection Type:
  • Connection Style:
  • Center Block Material: Polypropylene
  • ATEX:
  • Diaphragm Material: Viton/FKM
  • Elastomers: Viton Encapsulated, Viton/FKM, Viton/FKM
  • Fittings:
  • Displacement per Stroke (gal): 0.15
  • Inlet Size: 1.5
  • Discharge Pressure:
  • Inlet Connection Type: Flanged
  • Max Delivered Pressure: 0
  • Main Material: Polypropylene
  • Max Solids Size: 0.25
  • Model #: NPF40/PPPP/VT/VT/PTV/FL/B
  • Max Flow Rate (GPM): 84
  • Outlet Size: 1.5
  • Outlet Connection Type: Flanged
  • Porting Position: side Port Flanged
  • Max Discharge Pressure:
  • Valve Balls Material: Viton/FKM
  • Valve Seat O-Ring: Viton Encapsulated
  • Shipping Weight LBS: 41.00
  • Shipping Length IN: 18.80
  • Shipping Width IN: 11.80
  • Valve Seat Material: Polypropylene
  • Shipping Height IN: 26.30
  • SKU: NM4012681SP
  • Seal Material:
  • MPN: 40-12681
  • Customs Code: HTS Code 8413.50.00.50
    Schedule B Code 8413.50.00.50
    HS Code 8413.50.00
