Home / Warren Rupp® Sandpiper® Pumps / Sandpiper® S05B1S2TANS700 1/2 In S05 Top Discharge NPT Stainless Steel Pump, PTFE-Santoprene/PTFE Diaphragm

Sandpiper® S05B1S2TANS700 1/2 In S05 Top Discharge NPT Stainless Steel Pump, PTFE-Santoprene/PTFE Diaphragm

Part Number: S05B1S2TANS700.
The actual product may vary from images shown
$4,032.50
QTY:


S05B1S2TANS700. DETAILS

Please add as an RFQ or contact us for substitute Sandpiper® pump options as this pump is no longer available with the seat configuration.
Sandpiper® S05B1S2TANS700 1/2 In S05 Standard Duty Ball Metallic Stainless Steel Pump, PTFE-Santoprene/PTFE Diaphragm, PTFE Valve Seat Material, Aluminum Non-Wetted Material

Design Level 1

Pump Style Standard

This legendary pump has proven the test of time as a trusted, class-leading air-operated double-diaphragm (AODD) pump performing across a wide variety of markets and applications reliably for decades.

The SANDPIPER® 1/2 Inch S05 Metallic AODD Pump provides portability, versatility and power in a compact design. The S05 is equipped to handle abrasive fluids and small suspended solids with ease and dependability.

The durable bolted construction of the S05 is superior to the clamped-band construction pump, providing exceptional leak-free performance. This pump is designed to be driven by compressed air or nitrogen (if you require your pump to be driven by natural gas, check out the SANDPIPER® G05 pump).

S05B1S2TANS700. FEATURES
  • Serviceability: The air distribution system (ADS) is one of the most frequently serviced parts of any AODD pump. Only SANDPIPER®'s ESADS+ feature allows access to the complete ADS without removing the pump from service. Repair or clean in five minutes (ve
  • Trusted design: SANDPIPER®’S original ADS is fully interchangeable, repairable and inline-serviceable. Other manufacturers frequently change ADS designs, creating issues with interchangeability, obsolete inventory and increased cost of ownership.

S05B1S2TANS700. SPECS

  • Pump Type: AODD
  • Brand: SANDPIPER®
  • Wetted Material: Stainless Steel
  • Non-Wetted Material: Aluminum
  • Main Material:
  • Air Inlet Size: 0
  • Check Valve Seat: Ball
  • Check Valve Type:
  • Diaphragm Material: PTFE-Santoprene/PTFE
  • Porting Position: Top Discharge
  • Air Inlet Connection Type: NPT
  • Ball Material:
  • Displacement per Stroke (gal): 0.03
  • Elastomers: PTFE-Santoprene/PTFE
  • Inlet Size: 0.5
  • Inlet Connection Type:
  • Max Air Inlet Pressure:
  • Max FLow Rate: 15 GPM
  • Max Solids Size: 0.125
  • Outlet Size: 0.5
  • Outlet Connection Type: NPT
  • Shipping Weight LBS: 21.00
  • Manifold Gasket:
  • Shipping Length IN: 11.50
  • Shipping Width IN: 8.72
  • Shipping Height IN: 10.57
  • SKU: WRS05B1S2TANS700SP
  • Max Viscosity:
  • MPN: S05B1S2TANS700
  • Customs Code:
  • Seal Material:
