Nomad® 15-25465 1/2" Aluminum Pwr-Flo™ AODD Pump, Garlock®-NEO BACKED Diaphragm

Part Number: 15-25465
The actual product may vary from images shown
$1,681.63
QTY:


15-25465 DETAILS

Nomad® 15-25465 1/2" Aluminum Pwr-Flo™ AODD Pump, Garlock®-NEO BACKED Diaphragm

Model: NPF15/AAAA/TGN/TF/ATF/B/C/X
Similar and Comparable to Wilden® Standard P Series

The Nomad® PWR-FLO asymmetrical spool design (ASD) features the most efficient air system available. The anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applications. The air valve and center section is made of chemically resistant polypropylene.

The Nomad® PWR-FLO asymmetrical spool design (ASD) features the most efficient air system available. The anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applications. The air valve and center section is made of chemically resistant polypropylene.

  • Wetted End Material: Aluminum
  • Air Chamber Aluminum
  • Center Block: Aluminum
  • Air Valve: Aluminum
  • Valve Balls: PTFE
  • Valve Seats: Aluminum
  • O-Ring Material: PTFE
  • Connection: 0.5 Inch BSP, Clamped, ATEX

15-25465 FEATURES
  • Drop in replacement for Wilden® AODD pumps of equivalent make and size
  • Air driven double diaphragm pumps handle large solids and slurries
  • PWR-FLO™ asymmetrical spool design (ASD) features an efficient air system
  • The anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applications
  • The air valve and center section is made of chemically resistant polypropylene.

15-25465 SPECS

  • Pump Type: PWR-FLO NPF15
  • Brand: NOMAD®
  • Wetted Parts: Aluminum
  • Non-Wetted Material: Aluminum
  • Air Inlet Size: 0.25
  • Air Consumption:
  • Max Air Inlet Pressure: 125
  • Air Valve Material: Aluminum
  • Air Inlet Connection Type: BSP
  • Ball Material:
  • Center Block Material:
  • Connection Style:
  • ATEX: ATEX
  • Diaphragm Material: Garlock® - NEO BACKED
  • Displacement per Stroke (gal): 0.03
  • Elastomers: PTFE, PTFE
  • Fittings: Clamped
  • Inlet Size: 0.5
  • Discharge Pressure:
  • Inlet Connection Type:
  • Max Flow Rate (GPM): 15
  • Max Delivered Pressure: 0
  • Max Solids Size: 0.0625
  • Model #: NPF15/AAAA/TGN/TF/ATF/B/C/X
  • Outlet Size: 0.5
  • Main Material:
  • Outlet Connection Type: BSP
  • Porting Position: Center Ported
  • Max Discharge Pressure:
  • Valve Balls Material: PTFE
  • Valve Seat Material: Aluminum
  • Valve Seat O-Ring: PTFE
  • Shipping Weight LBS: 15.00
  • Shipping Length IN: 10.90
  • Shipping Width IN: 7.90
  • Shipping Height IN: 10.90
  • SKU: NM1525465SP
  • Seal Material:
  • MPN: 15-25465
  • Customs Code: Schedule B Code 8413.50.00.50
