AMT® 3S5XFR 3 Inch NPT Aluminum Diecast Self-Priming Engine Driven Trash Pump

Part Number: 3S5XFR
The actual product may vary from images shown
$1,136.25
QTY:


3S5XFR DETAILS

AMT® 3S5XFR 3 Inch NPT Aluminum Diecast Self-Priming Engine Driven Trash Pump

AMT Portable High Volume, Self-priming Centrifugal Trash pumps come standard with a cast iron impeller to resist abrasion and one tool serviceability for easy cleanout. Pumps are designed to handle liquids with solids content or dissolved solids and debris. All pumps feature aluminum housing, cast iron wearparts, built-in check valve, suction strainer and heavy duty steel roll frame. Heavy duty cast iron flanges with male NPT threads that rotates in 90° increments. Easy access fill plug on discharge port.


Horsepower Class: 5VAC at 60Hz: FALSEFALSE
Max Temp: 180

3S5XFR FEATURES

  • EPDM/EPR O-Rings Standard with Optional FKM
  • 2˝ or 3˝ Removable Male NPT Suction and Discharge Ports
  • Discharge Rotates in 90° Increments
  • Engine Options: Honda, CRX Gasoline or Hatz Diesel Engines
  • Easy Clean Out with One Tool Serviceability
  • Maximum Solids Handling up to 1-1/4˝
  • Solids Handling and Dirty Water Design
  • Maximum Flow up to 290 GPM
  • Maximum Head up to 125 Ft.
  • Self-Priming to 26 Ft.
  • Wheel Kit Optional

3S5XFR SPECS

  • Pump Type: Trash Centrifugal
  • Brand: AMT®
  • Shipping Weight LBS: 100
  • Shipping Length IN: 24
  • Main Material: Aluminum Diecast
  • Displacement per Stroke (gal):
  • Shipping Height IN: 7.4
  • SKU: AT3S5XFRSP
  • Engine Type:
  • MPN: 3S5XFR
  • Full Load Current:
  • Customs Code:
  • Driver Type: Gasoline Engine
  • Fuel Tank Capacity: 0.87 Gal 3.3 Ltr, not qt
  • Shipping Width IN: 19.5
  • Outlet Size: 3
  • Inlet Size: 3
  • Motor Frame:
  • Outlet Connection Type: NPT
  • Model #:
  • Max FLow Rate: 290 GPM
  • Run Time: 120.00 min
  • Power: 5
  • Porting Position:
  • Elastomers:
  • RPM:
  • Max Solids Size: 1.25
  • Seal Material:
  • Max Discharge Pressure:
  • Inlet Connection Type:
